Find 1x2 Plc Splitter, Optic PLC Splitter, Fiber Optic PLC Splitter on Industry Directory, Reliable Manufacturer/Supplier/Factory from China.

Home > Products > PLC > PLC 1x2 SC APC fiber optic PLC Splitter

PLC 1x2 SC APC fiber optic PLC Splitter

  • PLC 1x2 SC APC fiber optic PLC Splitter
  • PLC 1x2 SC APC fiber optic PLC Splitter
  • PLC 1x2 SC APC fiber optic PLC Splitter
  • PLC 1x2 SC APC fiber optic PLC Splitter

PLC 1x2 SC APC fiber optic PLC Splitter

    Packaging: 10pcs/blister Splitter PLC 1x 2 SC APC fiber optic PLC Splitter
    Transportation: Express,Ocean,Land,Air
    Supply Ability: 200000 Piece/Pieces per Day
    Port: ,,

Product Description

Products Description

Splitter PLC 1x 2 SC APC fiber optic PLC Splitter


Factory FTTH 1x2 1x4 1x8 1x16 Fiber Optic PLC Splitter SC UPC/APC Connector
Product Features:
* Good uniformity and low insertion loss
* Low Polarization Dependent Loss
* Excellent Environmental Stability
* Excellent Mechanical
* Stability Telcordia GR-1221 and GR-1209

Application:
* Fiber to The Home (FTTH)
* Passive optical networks (PON)
* Local Area Networks (LAN)
* Cable Television (CATV)
* Test Equipment
optic PLC Splitter
optic PLC Splitter
optic PLC Splitter
Configuration Type

1×2
1×4
1×8
1×16
1×32
1×64
1×128
Fiber Type

G657.A






Operating Wavelength

1260-1650nm






Insertion Loss(dB)
Without Connector
≤3.8
≤7.4
≤10.4
≤13.5
≤16.8
≤20.5
≤23.5

With Connector
≤4.1
≤7.6
≤10.7
≤13.8
≤17.2
≤20.8
≤23.8
Channel uniformity(dB)
Fixed Operating Wavelength
≤0.6
≤0.7
≤0.8
≤1.2
≤1.5
≤2.0
≤2.5

Full Operating Wavelength
≤1.1
≤1.2
≤1.5
≤1.7
≤2
≤2.5
≤3
Polarization Dependent Loss(dB)

≤0.2
≤0.2
≤0.3
≤0.3
≤0.3
≤0.3
≤0.5
Return Loss(dB)

≥55(UPC) / ≥ 55(APC) / PLC Parts ≥ 55






Directivity(dB)

≥55






Operating Temperature(°C)

-40~+85






Certifications

CIXI LANGUANG PHOTOELECTRIC TECHNOLOGY CO..LTD

  • 1
  • 2
  • 3
 Cixi city blu-ray photoelectric technology coLTD was founded in 1996We have a complete R&D system advanced production and testing equipments,and have established a quality assurance system in accordance with the ls09001 standards.After 20 years of development in thecommunication and network field our company now provides a full range of products andsolutions in the Generic Cabling System(ALL-LAN),FTTH(FTTX) system and MDF system.The main products contain:110 wiring block,patch panelcable traykeystone jack, face plate, profile FTmodule, disconnection module, 10 pair toolless module; fiber optic products as fiber optic Distribution BOX,fiber optic adapter and connector fiber optic splice travfiber optic batch banel and FTTH installation material MDE system products as MDFterminal block,protection unit,etc.The products have past the tests from the Ministry of In formation Industry of China.Lisen always keeps 'quality, service'as the guiding principle.With the innovative technology and scientific management, we are ready to effectively provide all kinds of standard products and customized products for you!
